Stiga Estate 9102 WX (2T1430381-ST2 (2025)) Parts Diagram, Transmission with Electromagnetic Clutch

Name: DIY Spare Parts Warehouse & Click & Collect Point
Address: The Barn, Shearstock Estate, Shaftesbury, Dorset, SP7 9PT, GB
Telephone: +441747823039

Look at the diagram and find parts that fit a Stiga Estate 9102 WX, or refer to the list below.

All Parts for Estate 9102 WX

Stiga Estate 9102 WX (2T1430381-ST2 (2025)) Parts Diagram, Transmission with Electromagnetic Clutch

#	Part	Price
1	118399062/1 Stiga Electromagnetic Clutch I-5217-38	£351.50	Stiga Electromagnetic Clutch I-5217-38 £351.50 P/N: 118399062/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
2	125430210/1 Stiga Brake Spring	£2.68	Stiga Brake Spring £2.68 P/N: 125430210/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
3	125601580/0 Stiga Pulley	£59.12	Stiga Pulley £59.12 P/N: 125601580/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
4	125160059/0 Stiga Pulley Spacer L=25.8	£7.52	Stiga Pulley Spacer L=25.8 £7.52 P/N: 125160059/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
5	112737320/0 Stiga Threaded Screw 7/16" X 3" 20 Unf	£4.37	Stiga Threaded Screw 7/16" X 3" 20 Unf £4.37 P/N: 112737320/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
6	112543000/0 Stiga Safety Washer D=7/16	£1.55	Stiga Safety Washer D=7/16 £1.55 P/N: 112543000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
7	135062029/0 Stiga Transmission Belt C531	£113.11	Stiga Transmission Belt C531 £113.11 P/N: 135062029/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
8	125160054/0 Stiga Spacer	£4.22	Stiga Spacer £4.22 P/N: 125160054/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
9	112793905/0 Stiga Hex-Head Screw M8 X 70	£1.97	Stiga Hex-Head Screw M8 X 70 £1.97 P/N: 112793905/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
10	112155000/0 Stiga Low Self-Locking Nut M8 Uni7474 6S Wz	£1.55	Stiga Low Self-Locking Nut M8 Uni7474 6S Wz £1.55 P/N: 112155000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
11	125510168/0 Stiga Pin Bolt	£4.50	Stiga Pin Bolt £4.50 P/N: 125510168/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
12	325670011/0 Stiga Anti-Friction Washer 8.2 X 19 X 0.8	£1.55	Stiga Anti-Friction Washer 8.2 X 19 X 0.8 £1.55 P/N: 325670011/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
13	112155000/0 Stiga Low Self-Locking Nut M8 Uni7474 6S Wz	£1.55	Stiga Low Self-Locking Nut M8 Uni7474 6S Wz £1.55 P/N: 112155000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
14	125840005/0 Stiga Tie Rod	£2.95	Stiga Tie Rod £2.95 P/N: 125840005/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
15	112293200/0 Stiga Hexagon Nut M8 Uni 5588 Acc.6S	£1.55	Stiga Hexagon Nut M8 Uni 5588 Acc.6S £1.55 P/N: 112293200/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
16	125430219/1 Stiga Spring	£3.67	Stiga Spring £3.67 P/N: 125430219/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
17	125601554/0 Stiga Pulley	£25.68	Stiga Pulley £25.68 P/N: 125601554/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
18	112523060/0 Stiga Washer M8 8.4 X 24 X 2 Uni 6593	£1.55	Stiga Washer M8 8.4 X 24 X 2 Uni 6593 £1.55 P/N: 112523060/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
19	112155000/0 Stiga Low Self-Locking Nut M8 Uni7474 6S Wz	£1.55	Stiga Low Self-Locking Nut M8 Uni7474 6S Wz £1.55 P/N: 112155000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
20	325601599/0 Stiga Steel Pulley	£19.14	Stiga Steel Pulley £19.14 P/N: 325601599/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
22	112523060/0 Stiga Washer M8 8.4 X 24 X 2 Uni 6593	£1.55	Stiga Washer M8 8.4 X 24 X 2 Uni 6593 £1.55 P/N: 112523060/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
23	112155000/0 Stiga Low Self-Locking Nut M8 Uni7474 6S Wz	£1.55	Stiga Low Self-Locking Nut M8 Uni7474 6S Wz £1.55 P/N: 112155000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
24	382318251/1 Stiga Lever		Stiga Lever £43.64 P/N: 382318251/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories. No longer available
25	125038002/1 Stiga Bush	£1.55	Stiga Bush £1.55 P/N: 125038002/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
26	112523060/0 Stiga Washer M8 8.4 X 24 X 2 Uni 6593	£1.55	Stiga Washer M8 8.4 X 24 X 2 Uni 6593 £1.55 P/N: 112523060/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
28	112155000/0 Stiga Low Self-Locking Nut M8 Uni7474 6S Wz	£1.55	Stiga Low Self-Locking Nut M8 Uni7474 6S Wz £1.55 P/N: 112155000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
29	125109521/1 Stiga Cover	£1.55	Stiga Cover £1.55 P/N: 125109521/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
30	325601570/1 Stiga Belt Pulley	£24.36	Stiga Belt Pulley £24.36 P/N: 325601570/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
31	112691115/0 Stiga Hex-Head Screw M8 X 40	£1.55	Stiga Hex-Head Screw M8 X 40 £1.55 P/N: 112691115/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
32	127160064/0 Stiga Pulley Spacer	£5.06	Stiga Pulley Spacer £5.06 P/N: 127160064/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
33	112691400/0 Stiga Hex-Head Screw M8 X 50 Uni 5737 8.8	£1.55	Stiga Hex-Head Screw M8 X 50 Uni 5737 8.8 £1.55 P/N: 112691400/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
34	125160024/2 Stiga Pulley Spacer	£8.29	Stiga Pulley Spacer £8.29 P/N: 125160024/2, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
35	382601522/0 Stiga Pulley [Ntn]	£23.92	Stiga Pulley [Ntn] £23.92 P/N: 382601522/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
40	125160056/0 Stiga Pulley Spacer	£4.66	Stiga Pulley Spacer £4.66 P/N: 125160056/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
41	118400975/0 Stiga Hydro Transaxle K574D	£1,401.84	Stiga Hydro Transaxle K574D £1,401.84 P/N: 118400975/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
42	112691800/0 Stiga Hex-Head Screw M8 X 60 Uni 5737	£1.55	Stiga Hex-Head Screw M8 X 60 Uni 5737 £1.55 P/N: 112691800/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
43	112154210/0 Stiga Self-Lock Winged Nut M8 Din 6927	£1.69	Stiga Self-Lock Winged Nut M8 Din 6927 £1.69 P/N: 112154210/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
44	382785175/0 Stiga Support	£87.28	Stiga Support £87.28 P/N: 382785175/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
45	112793102/0 Stiga Screw Te M8X20 Uni 5739 Acc.8.8	£1.55	Stiga Screw Te M8X20 Uni 5739 Acc.8.8 £1.55 P/N: 112793102/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
46	112293201/0 Stiga Flanged Hexagon Nut M8	£1.69	Stiga Flanged Hexagon Nut M8 £1.69 P/N: 112293201/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
47	112792611/0 Stiga Screw Te M8 X 16 Uni 5739 Acc.8.8	£1.55	Stiga Screw Te M8 X 16 Uni 5739 Acc.8.8 £1.55 P/N: 112792611/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
48	112293201/0 Stiga Flanged Hexagon Nut M8	£1.69	Stiga Flanged Hexagon Nut M8 £1.69 P/N: 112293201/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
49	112691115/0 Stiga Hex-Head Screw M8 X 40	£1.55	Stiga Hex-Head Screw M8 X 40 £1.55 P/N: 112691115/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
50	112521350/0 Stiga Washer M8 8.4 X 16 X 1.6	£1.55	Stiga Washer M8 8.4 X 16 X 1.6 £1.55 P/N: 112521350/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
51	112155000/0 Stiga Low Self-Locking Nut M8 Uni7474 6S Wz	£1.55	Stiga Low Self-Locking Nut M8 Uni7474 6S Wz £1.55 P/N: 112155000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
52	325547229/0 Stiga Plate		Stiga Plate P/N: 325547229/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories. No longer available
53	125580031/0 Stiga Belt Guide	£4.08	Stiga Belt Guide £4.08 P/N: 125580031/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
54	127510111/0 Stiga Fulcrum Pin	£2.53	Stiga Fulcrum Pin £2.53 P/N: 127510111/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
55	125033079/0 Stiga Brake Rod	£11.53	Stiga Brake Rod £11.53 P/N: 125033079/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
56	112604896/0 Stiga Starlock Washer D=6	£1.55	Stiga Starlock Washer D=6 £1.55 P/N: 112604896/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
57	124487997/0 Stiga Spring Clip D=1.8	£1.55	Stiga Spring Clip D=1.8 £1.55 P/N: 124487997/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
58	114363696/0 Stiga Hydro Release Lever Decal	£3.10	Stiga Hydro Release Lever Decal £3.10 P/N: 114363696/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
71	182001504/0 Stiga Rear Wheel Rim 6" X 10"	£119.66	Stiga Rear Wheel Rim 6" X 10" £119.66 P/N: 182001504/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
72	125950000/0 Stiga Pneumatic Valve	£5.35	Stiga Pneumatic Valve £5.35 P/N: 125950000/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
73	125590030/0 Stiga Tyre 20 X 10.00-10 [Wanda] Ply4 P519B	£125.99	Stiga Tyre 20 X 10.00-10 [Wanda] Ply4 P519B £125.99 P/N: 125590030/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
74	325670025/0 Stiga Spacer Washer	£4.08	Stiga Spacer Washer £4.08 P/N: 325670025/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
75	112521410/0 Stiga Washer M20 21 X 37 X 3	£1.82	Stiga Washer M20 21 X 37 X 3 £1.82 P/N: 112521410/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
76	125160023/0 Stiga Wheels Spacer Gr.Transm. Tuff Torq TC Hy	£7.31	Stiga Wheels Spacer Gr.Transm. Tuff Torq TC Hy £7.31 P/N: 125160023/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
77	125670005/2 Stiga Spindle Washer	£4.08	Stiga Spindle Washer £4.08 P/N: 125670005/2, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
78	112001010/0 Stiga Circlip Id=0.580" Th=0.050"	£1.82	Stiga Circlip Id=0.580" Th=0.050" £1.82 P/N: 112001010/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
79	125670007/0 Stiga Fixing Washer	£1.97	Stiga Fixing Washer £1.97 P/N: 125670007/0, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
80	382680075/1 Stiga Wheel Assembly 20" [Wanda] P519 B	£246.35	Stiga Wheel Assembly 20" [Wanda] P519 B £246.35 P/N: 382680075/1, Genuine OEM spare part. Find other Stiga spares, parts and accessories.
