Stihl MS 460 Chainsaw (MS460 Magnum) Parts Diagram, Cylinder

#	Part	Price
1a	1128 020 1221 - Stihl Cylinder and piston 52mm	£288.72	To Basket
1b	1128 029 2306 - Stihl Cylinder gasket 0.8mm	£3.10	To Basket
2	1128 030 2009 - Stihl Piston 52mm	£135.96	To Basket
3	1122 034 3000 - Stihl Piston ring 52mm	£11.57	To Basket
4	1128 034 1501 - Stihl Piston pin K12X8X35-X1	£7.25	To Basket
5	9463 650 1200 - Stihl Snap ring DIN73130-C12x1	£0.56	To Basket
6	9512 003 3061 - Stihl Needle cage 12x15x15	£7.46	To Basket
7	1128 029 2304 - Stihl Cylinder gasket 0.3mm	£3.10	To Basket
8	9022 341 1370 - Stihl Spline screw IS-M6x30	£1.13	To Basket
9	1128 020 9400 - Stihl Decompression valve	£30.11	To Basket
10	1122 084 1405 - Stihl Cover	£2.93	To Basket
11	1128 141 3200 - Stihl Cooling plate	£7.56	To Basket
12	1125 149 0601 - Stihl Muffler gasket	£2.88	To Basket
13	1128 141 2203 - Stihl Manifold	£41.06	To Basket
14	9771 021 2578 - Stihl Hose clamp 34x5	£2.11	To Basket
15a	0000 400 7000 - Stihl Spark plug NGK BPMR7A	£3.78	To Basket
15b	0000 400 7000 - Stihl Spark plug NGK BPMR7A	£3.78	To Basket
16	1128 084 1400 - Stihl Cover	£2.72	To Basket
17	1128 405 1000 - Stihl Spark plug boot	£6.22	To Basket
18	0000 998 0604 - Stihl Torsion spring	£1.26	To Basket
19	1128 007 1052 - Stihl Set of gaskets	£16.85	To Basket
