Stihl MS 250 Chainsaw (MS250 C) Parts Diagram, Handle Housing

Look at the diagram and find parts that fit a Stihl MS 250 Chainsaw, or refer to the list below.

All parts that fit a MS 250 Chainsaw




Stihl MS 250 Chainsaw (MS250 C) Parts Diagram, Handle Housing
# Part Price
1 1123 790 1022 - Stihl Handle housing £24.98
2 1123 790 1004 - Stihl Handle housing £24.60
3 1123 790 1017 - Stihl Handle housing £24.98
4 1123 790 1017 - Stihl Handle housing £24.98
5 1123 790 1015 - Stihl Handle housing £22.60
6 1128 182 1005 - Stihl Throttle trigger £3.18
7 1117 182 0805 - Stihl Lever £3.49
8 1117 182 4500 - Stihl Hook on spring £1.08
9 9371 470 2640 - Stihl Cylindrical pin (DIN7) - 5m6x24 £0.47
10 4130 350 6200 - Stihl Fuel pump £9.90
14 1123 123 7503 - Stihl Grommet £1.50
15 1123 123 7503 - Stihl Grommet £1.50
16 1123 123 7504 - Stihl Grommet £1.67
17 0000 350 5802 - Stihl Tank vent £4.12
18 1123 353 2700 - Stihl Connecting piece £2.08
22 1125 122 6600 - Stihl Collar screw £1.42
23 1123 791 7310 - Stihl Plug £0.48
24 1123 442 1602 - Stihl Contact spring £1.58
25 1123 791 0600 - Stihl Handle moulding £4.13
26 1123 791 2805 - Stihl Annular buffer £5.95
27 1123 182 1505 - Stihl Throttle rod £2.05
28 1123 141 2200 - Stihl Manifold £22.75
29 1123 141 8600 - Stihl Impulse hose £2.83
30 1123 141 5600 - Stihl Baffle plate £5.36
31 1123 141 4001 - Stihl Slide £2.87
32 1123 791 7500 - Stihl Cover £2.35
33 1123 182 0901 - Stihl Switch shaft £5.41
34 9075 478 3015 - Stihl Pan head self-tapping screw IS-D4x15 £0.58
35 1123 791 1702 - Stihl Handlebar £34.75
36 1123 791 1701 - Stihl Handlebar £36.34
37 9075 478 4155 - Stihl Pan head self-tapping screw IS-D5x24 £0.71
38 1123 353 7000 - Stihl Cover £1.72
41 0000 930 2802 - Stihl Hose 2.2x5.4 mm x 1 m £3.32
42 0000 930 2803 - Stihl Hose 3.1x5.7 mm x 1 m £3.32
Can't see your part?
