Stihl MS 180 Chainsaw (MS180C-B D) Parts Diagram, Engine Housing

Look at the diagram and find parts that fit a Stihl MS 180 Chainsaw, or refer to the list below.

All parts that fit a MS 180 Chainsaw




Stihl MS 180 Chainsaw (MS180C-B D) Parts Diagram, Engine Housing
# Part Price
2 1130 020 3011 - Stihl Engine housing £55.45
4 1120 162 5200 - Stihl Pin £1.57
5 1123 162 5200 - Stihl Pin £2.10
6 1123 162 5205 - Stihl Pin £2.28
7 1123 664 2400 - Stihl Collar screw £1.57
8 1121 122 6600 - Stihl Collar screw £1.40
9 1123 664 2402 - Stihl Collar screw £1.75
10 1130 084 8303 - Stihl Reflector foil £4.30
11 1130 145 3400 - Stihl Heat shield £3.25
12 9104 003 8600 - Stihl Self-tapping screw P3x10 £0.56
13 1123 640 3200 - Stihl Oil pump 0.55mm £23.65
14 1130 350 4400 - Stihl Oil tank £15.97
15 0000 359 1241 - Stihl Sealing ring £0.66
16 1130 647 9400 - Stihl Hose £4.43
17 1123 640 3800 - Stihl Pickup body £3.05
18 1130 350 0410 - Stihl FUEL TANK £13.52
19 0747 313 6810 - Stihl Valve £3.24
20 1130 358 7701 - Stihl Hose £6.34
21 0000 350 3500 - Stihl Pickup body £4.07
22 1130 350 0500 - Stihl Filler cap £5.12
23 0000 359 1240 - Stihl Sealing ring £1.16
24 0000 350 0905 - Stihl Rope £1.68
25 0000 353 0605 - Stihl Hook £0.92
Can't see your part?
